Flexitank is made of 100% virgin material confirmed by SGS, fully in compliance with the US FDA regulation and ISO 9001 : 2008, International Qulatity System Certification , HACCP system. We are the only manufacturer to get the FSSC 22000, which requires the most stringent standards in this industry.FSSC 22000, including ISO 22000:2005, PAS 223:2011 and FSSC 22000 additional demand.
| Name | Items | Testing Method | Standard | ||
|---|---|---|---|---|---|
| Inner PE Film | co-extruded, ultrahigh tensile, food grade polyethylene film | Thickness ( μm ) | ASTM D645 | 125 mic per layer (+- 5%) | |
| Tensile Strength (Mpa) | TD | ASTM D882 | ≥40 | ||
| MD | ASTM D882 | ≥40 | |||
| Elongation ( % ) | TD | ASTM D882 | ≥900 | ||
| MD | ASTM D882 | ≥900 | |||
| Tear Strength (KN/M) | TD | ASTM D1922 | ≥130 | ||
| MD | ASTM D1922 | ≥130 | |||
| Dart Impact | ASTM D1709 | 1800g | |||
| Welding Method | 6+2 | ||||
| Max. Load ( N ) | ASTM D882 | ≥90 | |||
| Tensile Strength (Mpa) | ASTM D882 | ≥40 | |||
| Outcover-PP Woven Fabric | Patent ONE-PIECE tubluar outcover technology | ||||
| Character | Max. Load ( N ) | Warp | GB/T1039 | ≥1900 | |
| Weft | GB/T1039 | ≥1900 | |||
| Elongation ( % ) | Warp | GB/T1039 | 18.8%≥a≥25% | ||
| Weft | GB/T1039 | 18.8%≥b≥25% | |||
| Description | Units | Quantity | Weight, Kg | Dimensions, (L x W x H) mm |
|---|---|---|---|---|
| Flexitank | Box | 1 | 46-48 | 1150 x 450 x 550 |
| Steel bars | Pcs | 5pcs / bags | 40 | 2400 x 50 x 50 |
| Bulkhead (Cardboard) | Pcs | 1 | 12 | 2330 x 1700 x 18 |
| Corrugated paper | Roll | 1 | 12 | 1500 x 280 diam |
| Total | 4 | 110-112 (+-2kg) | 0.5 cbm | |
Food stuff: flat beet, juice, wine, edible oil, glucose, molasses, syrup, sorbitol, water, jam, etc.
Non hazardous chemical stuff: base oil, lubricant, MEG, latex, glycerin, mineral oils, pharmaceutical ingredients, paints, shampoos, etc.
Capacity:
– 15000L-18000L-24000L – 25000L
Structure:
– Multi-layer triple co-extruded
– polyethylene blown films, seamless
– woven PP jacket, 3 inch BSP valve
Type:
– Bottom Load Bottom Discharge
– Top Load Top Discharge
– Top Load Bottom Discharge
